A30.5 is a five-channel power amplifier from the Swedish company Primare. The amplifier is equipped with five independent monophonic channels, each of which has its own separate powerful toroidal transformer and ultra-fast transistors. The input stage of each channel consists of one field-effect transistor, and the output stage consists of four powerful Toshiba transistors. Massive radiators keep the temperature at a moderate level even under the harshest operating conditions. The microprocessor Standby switch can be controlled using Primare processors or from a remote control. The design uses powerful radiators, which allows the component to operate at the highest power levels. The massive anti-vibration chassis contributes to the absence of any resonances. Switching is simple: five RCA inputs and five pairs of solid gold-plated screw terminals - it is convenient to use both “bananas”, “blades”, “needles”, and simply stripped wire.
Specifications
Output power: 5 x 120 W / 8 Ohm (200 W / 4 Ohm)
Inputs: 5 RCA
Other inputs: 12 V trigger
Frequency range: 10 Hz - 100 kHz, - 3 dB
THD: 0.08%
Signal to noise ratio: 100 dB
Input impedance: 10 kOhm
Output impedance: 0.03 Ohm
Dimensions (WxDxH): 430 x 385 x 175 mm
Weight: 27 kg
